| Model |
8FE+2FE SMART (Ai) PoE SWITCH |
| Transmission Rate: |
10/100Mbps |
| Function: |
PoE |
| Communication Mode: |
Full-Duplex & Half-Duplex |
| Certification: |
CE, RoHS |
| Switch Capacity: |
2Gbps |
| PSE Type: |
End-Span |
| Color: |
Grey/Black |
| Transfer Mode: |
Storage Transfer |
| Signal Pin: |
1,2 (+),3,6 (-) |
| Distance: |
Up to 250m |
| Dimension: |
227*144*44.8mm |
| PoE Budget: |
52V, 120W |
|
8 PoE Port at 10/100 each without missing data. |
|
2 Uplink 10/100 Mbps each |
|
Extend networking port can extend signal and distance up to 250m. |
| Poe Standard: |
IEE 802.3af, IEEE 802.3at |
|
Every port supports MDI/MDI auto flip and self-negotiation. |
|
Support CAT-5e or better access point (AP) and data transmission for networking camera. |
| Power Input: |
100-240V AC 50/60Hz |
